800 Line

Turning inserts with a length of 32 mm and with the "X-Centering" crossed-shaped fastening system.

Bar turning up to Ø 18 mm when using the inserts 800 with a width of 8,3 mm.

Available tool holder sections : 10x10, 12x12 and 16x16 mm.

Bar turning up to Ø 14 mm when using the inserts 800-8 with a width of 7,9 mm.

Thanks to the 800-8 inserts, possibility to user 8x8 mm section tool holders on cam controlled automatic lathes.
